Product Key Features
lEquipped with imported power, quality assurance,superior performance.
lEquipped with metal halide lamp, large luminous flux and long life.
lHigh performance self-braking hand winch.
l3-section lifting pole, galvanized light pole,anti drop, corrosion resistant.
lLeft and right wind proof support frame, stable support.
lIntegrated operator panel.
l5meters lifting height, adjustable irradiation angle,long irradiation distance.
Overall Size
|
SMLV400A/B Overall Size
|
|
Model
|
SMLV400A/B
|
|
Laydown support frame(mm)
|
1585*1740
|
|
Pack up support frame(mm)
|
1250*860
|
|
Lighthouse Telescopic(mm)
|
1700-5000
|
|
Luminous Flux(lm)
|
72000/144000
|
|
Power Number of lights(w)
|
400*2/400*4
|
Main technical parameters
|
Model
|
Unit
|
SMLV400A
|
SMLV400B
|
|
Gasoline generator
|
|
HONDA EC4000CX/LONCIN LC3500
|
|
Diesel generator
|
|
ANMAX DG3500CLE
|
|
Extemal contact power supply
|
Externally accessible
|
|
Name
|
|
Single phase alternator
|
|
Frequency
|
hz
|
50
|
|
Rated voltage
|
V
|
220
|
|
Maximum power
|
kva
|
3.20
|
|
Rated power
|
kva
|
3
|
|
Continuously working
|
hr
|
13
|
|
Fuel tank capacity
|
L
|
25
|
|
Engine weight
|
Kg
|
68
|
|
Engine size
|
mm
|
Metal Halide
|
LED lamp
|
|
lamp bulb
|
|
590*430*435
|
590*430*435
|
|
Power*Numberof lights
|
W
|
400*2
|
400*4
|
200*2
|
200*4
|
|
Luminous flux
|
Im
|
72000
|
144000
|
56000
|
112000
|
|
Light stand retractable
|
mm
|
1700-5000
|
|
Light stand operation
|
|
Three-section lift rod
|
|
Lifting method
|
|
Hand lift
|
|
Inclination
|
|
<10
|
|
Wind resistance
|
<6
|
|
L*W-Lay down support
|
mm
|
1585*1740
|
1585*1740
|
|
L*W-fold support
|
mm
|
1250*860
|
1250*860
|
|
Way of walking
|
|
Push type
|
|
Weight(excluding generator)
|
kg
|
112
|
116
|
