Overall Size
|
ST1500 Overall Size
|
|
Model
|
ST1500
|
|
Working Widthmm
|
930
|
|
Overall Heightmm
|
2125
|
|
Overall Lengthmm
|
1940
|
|
Drumdiametermm
|
1540
|
|
Drum Widthmm
|
800
|
|
Wheelbasemm
|
1356
|
Main technical parameters
|
ST1500Technical parameter
|
|
Model
|
Unit
|
ST1500
|
|
Weight
|
|
Operating weight
|
kg
|
1500
|
|
Static line load
|
n/cm
|
69.5/68
|
|
Size
|
|
Workingwidth
|
mm
|
930
|
|
Overalllength
|
mm
|
1980/1940
|
|
Overall height
|
mm
|
1540/2125
|
|
Outside the turning radius
|
mm
|
2800
|
|
Drum width
|
mm
|
800
|
|
Drum diameter
|
mm
|
560
|
|
Wheel base
|
mm
|
1356
|
|
Drive
|
|
Engine brand
|
|
CHANGCHAI
|
|
Engine model
|
|
192F
|
|
Engine type
|
|
Single cylinder vertical air cooling four-stroke diesel engine
|
|
Number of cylinders
|
|
1
|
|
Output Power
|
kw
|
8.1
|
|
Rotating speed
|
rpm
|
3600
|
|
Electrical equipment
|
V
|
12
|
|
Driving mode
|
|
Variable displacement piston pump infinitely variable two-wheel series
|
|
Walking characteristics
|
|
Speed
|
km/h
|
0-6
|
|
Theoretical climbing ability
|
%
|
30
|
|
Brake
|
|
Service brake
|
|
Variable displacement piston pump
|
|
Turn
|
|
Steering method
|
|
Hydraulic steering
|
|
Steering system
|
|
Swing articulated
|
|
Vibration system
|
|
Vibrating drum
|
|
Front
|
|
Drive form
|
|
Mechanical transmission Electromagnetic clutch
|
|
vibration frequency
|
hz
|
65
|
|
Vibration amplitude
|
mm
|
0.5
|
|
Exciting force
|
kn
|
30
|
|
Sprinkler system
|
|
Form
|
|
Intermittent pressure spray
|
|
Capacity
|
|
Fuel capacity
|
L
|
5.5
|
|
Hydraulic oilcapacity
|
L
|
22
|
|
Water tank capacity
|
L
|
70
|
Product Key Features
lEquipped with famous brand power, quality assurance, superior performance.
lEagle-eye body design, wide field of vision, beautiful and generous.
lImported hydraulic variable pump and quantitative motor, stepless speed change, walking forward and backward.
lThe control panel is fully functional, one-key operation.
lFront and rear lighting & warning lights, can be constructed at night.
lErgonomic driving
lThe steel wheel is equipped with an outline light,which is easy to operate, safe and efficient.
lThe product has passed CE certification,and the design of the Red Star Award.
