Main technical parameters
|
020272 Closed Sweeper Technical Parameters
|
|
Model
|
020272C (Domestic Motor)
|
020272BImported Motor
|
|
Lengthmm
|
1442
|
1442
|
|
Widthmm
|
2082
|
2137
|
|
Heightmm
|
677
|
677
|
|
Total Weightkg
|
495
|
495
|
|
Hopper Volume (m3)
|
0.46
|
0.46
|
|
Effective Sweeping Width (mm)
|
1830
|
1830
|
|
Brush Roller Dia. (mm)
|
660
|
660
|
|
Max. Pressure (Mpa)
|
21
|
21
|
|
Work FlowL/Min
|
60-80
|
60-80
|
|
Compatible Equipment
|
Skid steer loader & Compact loader
|
Skid steer loader & Compact loader
|
|
Optional Accessories
|
Fog Dust Suppression System, Side Brush Cleaning System, Foot Pedal, Crash Beam, Quick Coupler (Imported or Domestic)
|
Product Key Features
This attachment can be installed on skid steer loaders, compact loaders, etc., to clean dust and debris from road surfaces. It efficiently cleans parking lots, sidewalks, docks, warehouses, and ports. Collected waste can be stored in the hopper and transported to designated areas. Effectively solves pre-paving road cleaning challenges with high efficiency and excellent construction results.
1. Hydraulic drive enables bidirectional sweeping. Replaceable wear-resistant plate on hopper bottom extends service life.
2. Hybrid bristle brush combines:
l High-elasticity, wear-resistant polyethylene polypropylene engineering plastic bristles
l High-elasticity, wear-resistant 32SiMnTi steel wires
Significantly improves brush lifespan and cleaning effectiveness.
3. Motor end features anti-tangling device to prevent filamentous material entanglement.
4. Unique anti-overturning design prevents excessive hood rotation that could damage operator cabins.
5. Optional side brush system for roadside, wall-edge, and gutter cleaning.
6. Available high-pressure fog dust suppression system for dust control.
7. For compact loader adaptation: Customers should install (dump/retract) limit blocks according to host machine configuration.
